Amphenol AHDP06-24-07SN-STACL22 Rectangular female cable connector 100A Rated Heavy Duty IP68 IP69K Waterproof Automotive Socket
| Place of Origin | USA |
|---|---|
| Brand Name | Amphenol |
| Certification | ROHS |
| Model Number | AHDP06-24-07SN-STACL22 |
| Minimum Order Quantity | 100 |
| Price | 10USD |
| Packaging Details | Tape & Reel (TR) |
| Delivery Time | 2~3 weeks |
| Payment Terms | T/T |
| Supply Ability | 10000 |
Product Details
You can tick the products you need and communicate with us in the message board.
| Model | |
|---|---|
| AHDP06-24-07SN-STACL22 | |
| AHDP06-24-07SN-STA | |
| AHDP06-24-07PN-STA |
Product Description
Amphenol AHDP06-24-07SN-STACL22 Rectangular female cable connector 100A Rated Heavy Duty IP68 IP69K Waterproof Automotive Socket
Description
The AHDP06-24-07SN-STACL22 is an Amphenol automotive female cable connector with IP68/IP69K high-level ingress protection under mated status across full operating temperature range from -55°C to 125°C. It features stable electrical performance, superior waterproof & dustproof capability and consistent contact conductivity, which make it ideal for heavy-duty automotive wiring harness and cable assembly applications. This 7-position connector adopts #16 specification contact diameter, rated for 100A at 40°C and 250V working voltage, compatible with wire gauge ranging from 0.34 to 16. The AHDP06-24-07SN-STACL22 connector is available in standard bulk packaging.
Features
7 Positions Automotive Female Cable Connector, #16 Contact Diameter
IP68 / IP69K Heavy-Duty Ingress Protection When Mated
Rated Current: 100A @40°C, Rated Voltage: 250V
Wide Operating Temperature Range from -55°C to +125°C, applicable for wire gauge 0.34~16
Totally Lead-Free; RoHS Compliant
Standard Bulk Packing
Totally Lead-Free & Fully RoHS Compliant
Halogen and Antimony Free. “Green” Device
Applications
Charger
Voltage Adapter
Switching Power Supply
Graphic Card
Precision Voltage Reference
| Category | Automotive / Board Mount Rectangular Socket Connector |
|---|---|
| Mfr | Amphenol |
| Product Status | Active |
| Voltage - Output (Max) | 250 V |
| Current - Output | 100 A @40°C |
| Operating Temperature | -55°C ~ +125°C |
| Mounting Type | Board Mount |
| Package / Case | Bulk Pack |
| Number of Positions | 7 Positions |
| Gender | Female |
| Contact Diameter | #16 |
| Mated IP Rating | IP68 / IP69K |
| Compatible Wire Gauge | 0.34 ~ 16 |
